iGor Almeida®

Repair Boot / Unlock com sucesso

Posts Recomendados

Espaço para Postar todo Repair Boot / Desbloqueio com a Medusa Box!

Qualquer assunto fora citado acima será excluído sem aviso.

Obs: Procedimentos retirados de outros Fóruns / Blogs não são aceitos e serão excluidor. Postar apenas o que você conseguir.

E de preferencia PrintScrenn.

Compartilhar este post


Link para o post
Compartilhar em outros sites

Reparar Boot do Samsung I9000 Pela medusa!

Ai vai o passo a passo como recuperar o Boot do Samsung I9000.

Vamos do que precisamos no processo todo.

  • Medusa
  • Cabo USB
  • Fonte ou Bateria totalmente carregada
  • Odin
  • Flash compatível com a sua versão.

Siga o procedimento que fiz por imagem para ficar mais fácil pra todo mundo.

  • Procedimento dos pinos

Posted Image

Posted Image

Posted Image

  • Procedimento na Medusa

Posted Image

Posted Image

Posted Image

Posted Image

Posted Image

  • Procedimento no Odin

Posted Image

Posted Image

Procedimento Concluído!

Compartilhar este post


Link para o post
Compartilhar em outros sites

Medusa JTAG Firmware version 1.1.0. Medusa JTAG Hardware S64 revision C. Detected TAP ID: 200C00E1, IR Length = 4. JTAG speed : Auto (RTCK). VREF level : 2.60 V CPU : Qualcomm MSM6280 Core ID : 200C00E1 Flash device: Samsung OneNAND KFW4G16Q2M Flash ID : 00EC005C Page size : 2048 bytes Block size : 64 pages (128 Kb) Block count: 4096 Flash size : 512 Mb Write protection disabled. Opening "C:\Arquivos de programas\GsmServer\Medusa\Firmware\SAMSUNG_SGHF480_Repair.mf" file... Writting BOOT section. Please wait... Done Disconnected Repair done. post-132-139967760657_thumb.jpg

Compartilhar este post


Link para o post
Compartilhar em outros sites

Modelo seleccionado do dispositivo: Samsung GT-S5260

Conexão...

Insuficiente nível de tensão VREF = 0.0 В. Por favor, verifique o estado de alimentação do dispositivo.

Medusa JTAG Firmware version 1.1.0.

Medusa JTAG Hardware S64 revision C.

Detected TAP ID: 07926F0F, IR Length = 4.

Velocidade JTAG : Auto (RTCK)

Nível de VREF : 2.61 V

Tipo do núcleo : Broadcom BCM2133

ID do núcleo: 07926F0F

Tipo da flash: Samsung OneNAND KFH2G16Q2M

ID da flash: 00EC0040

Tamanho da página: 2048 bytes

Tamanho do bloco: 64 páginas (128 Kb)

Quantidade dos blocos : 2048

Tamanho total da flash : 256 Mb

A protecção contra escritura está desactivada.

Está aberto o arquivo "C:\Arquivos de programas\GsmServer\Medusa\Firmware\SAMSUNG_GTS5260_Repair.mf"...

Escritura da secção BOOT. Aguarde, por favor... Terminado

Escritura da secção UPCH. Aguarde, por favor... Terminado

IMEI corrigido... Terminado

Desconectado.

Reparação terminada.

O procedimento foi realizado porem o atc nao ligou, nem em modo download, provavel defeito fisico na placa.


Compartilhar este post


Link para o post
Compartilhar em outros sites

S3650 (Corby)

Modelo seleccionado do dispositivo: Samsung GT-S3650
Conexão...
Insuficiente nível de tensão VREF = 0.0 ?. Por favor, verifique o estado de alimentação do dispositivo.
MI: RTCK reaction time 126 ns, average speed 7936 KHz.
Medusa JTAG Firmware version 1.1.0.
Medusa JTAG Hardware S64 revision C.
Detected TAP ID: 07926F0F, IR Length = 4.
MI: Halting target, attempt 1.
Velocidade JTAG : Auto (RTCK)
Nível de  VREF  : 3.1 V
Tipo do núcleo : Broadcom BCM2133
ID do núcleo: 07926F0F
MI: Loading Medusa Device Server V1.2.
MI: Starting...
MI: Received status 0x0000F00F, cycle 0.
MI: Received server capabilities 0x00000035.
MI: Detailed server caps: FLASH, ECC, WDOG, DWP
MI: Watchdog are preconfigured.
MI: Server init.
MI: Received flash ID 0xA0EC55BA.
MI: Flash geometry set.
MI: Recheking settings... ok
Iconos do servidor : 00000035
Tipo da flash: Samsung KF92G16
ID da flash: 00EC55BA
 Tamanho da página: 2048 bytes
 Tamanho do bloco: 64 páginas (128 Kb)
 Quantidade dos blocos : 2048
 Tamanho total da flash : 256 Mb
A protecção contra escritura está desactivada.
Está aberto o arquivo "C:\Arquivos de programas\GsmServer\Medusa\Firmware\SAMSUNG_GTS3650_Repair.mf"...
Escritura da secção BOOT. Aguarde, por favor... Terminado
Escritura da secção UPCH. Aguarde, por favor... Terminado
IMEI corrigido... Terminado
Desconectado.

Compartilhar este post


Link para o post
Compartilhar em outros sites

Reparo do Boot s8500 100% com sucesso. Modelo seleccionado do dispositivo: Samsung GT-S8500 Conexão... Insuficiente nível de tensão VREF = 0.0 ?. Por favor, verifique o estado de alimentação do dispositivo. Medusa JTAG Firmware version 1.1.0. Medusa JTAG Hardware S64 revision C. Detected TAP ID: 1BA00477, IR Length = 4. MI: Halting target, attempt 1. MI: ARM CoreSight DAP detected. MI: CPUID = 43110222. Velocidade de JTAG : 8000 KHz. Nível de VREF : 2.81 V Tipo do núcleo : Samsung S5PC110 ID do núcleo: 1BA00477 MI: Loading Medusa Device Server V1.2. MI: Starting... MI: Received status 0x0000F00F, cycle 0. MI: Received server capabilities 0x00000135. MI: Detailed server caps: FLASH, ECC, WDOG, DWP, IOCTL MI: Watchdog are preconfigured. MI: Server init. MI: Received flash ID 0xB0EC0050. MI: Flash geometry set. MI: Recheking settings... ok Iconos do servidor : 00000135 Tipo da flash: Samsung OneNAND KFG4GH6Q4M ID da flash: 00EC0050 Tamanho da página: 4096 bytes Tamanho do bloco: 64 páginas (256 Kb) Quantidade dos blocos : 2048 Tamanho total da flash : 512 Mb A protecção contra escritura está desactivada. Está aberto o arquivo "C:\Documents and Settings\USER\Desktop\Download \SAMSUNG_GTS8500_Repair.mf"... Escritura da secção BOOT. Aguarde, por favor... ERROR[018]: Error de operação com o bloco lógico 368 Kb (Hex address 0x0005C000). Razáo: Connection lost. Insuficiente nível de tensão VREF = 0.0 ?. Por favor, verifique o estado de alimentação do dispositivo. Medusa JTAG Firmware version 1.1.0. Medusa JTAG Hardware S64 revision C. Detected TAP ID: 1BA00477, IR Length = 4. MI: Halting target, attempt 1. MI: ARM CoreSight DAP detected. MI: CPUID = 43110222. Velocidade de JTAG : 8000 KHz. Nível de VREF : 2.81 V Tipo do núcleo : Samsung S5PC110 ID do núcleo: 1BA00477 MI: Loading Medusa Device Server V1.2. MI: Starting... MI: Received status 0x0000F00F, cycle 0. MI: Received server capabilities 0x00000135. MI: Detailed server caps: FLASH, ECC, WDOG, DWP, IOCTL MI: Watchdog are preconfigured. MI: Server init. MI: Received flash ID 0xB0EC0050. MI: Flash geometry set. MI: Recheking settings... ok Iconos do servidor : 00000135 Tipo da flash: Samsung OneNAND KFG4GH6Q4M ID da flash: 00EC0050 Tamanho da página: 4096 bytes Tamanho do bloco: 64 páginas (256 Kb) Quantidade dos blocos : 2048 Tamanho total da flash : 512 Mb A protecção contra escritura está desactivada. Está aberto o arquivo "C:\Documents and Settings\USER\Desktop\Download \SAMSUNG_GTS8500_Repair.mf"... Escritura da secção BOOT. Aguarde, por favor... ERROR[018]: Error de operação com o bloco lógico 512 Kb (Hex address 0x00080000). Razáo: Connection lost. Medusa JTAG Firmware version 1.1.0. Medusa JTAG Hardware S64 revision C. Detected TAP ID: 1BA00477, IR Length = 4. MI: Halting target, attempt 1. ERROR[000]: Impossível parar o núcleo. MI: Halting target, attempt 2. ERROR[000]: Impossível parar o núcleo. MI: Halting target, attempt 3. ERROR[000]: Impossível parar o núcleo. Por favor, conecte o dispositivo e ligue o... Medusa JTAG Firmware version 1.1.0. Medusa JTAG Hardware S64 revision C. Detected TAP ID: 1BA00477, IR Length = 4. MI: Halting target, attempt 1. MI: ARM CoreSight DAP detected. MI: CPUID = 43110222. Velocidade de JTAG : 8000 KHz. Nível de VREF : 2.81 V Tipo do núcleo : Samsung S5PC110 ID do núcleo: 1BA00477 MI: Loading Medusa Device Server V1.2. MI: Starting... MI: Received status 0x0000F00F, cycle 0. MI: Received server capabilities 0x00000135. MI: Detailed server caps: FLASH, ECC, WDOG, DWP, IOCTL MI: Watchdog are preconfigured. MI: Server init. MI: Received flash ID 0xB0EC0050. MI: Flash geometry set. MI: Recheking settings... ok Iconos do servidor : 00000135 Tipo da flash: Samsung OneNAND KFG4GH6Q4M ID da flash: 00EC0050 Tamanho da página: 4096 bytes Tamanho do bloco: 64 páginas (256 Kb) Quantidade dos blocos : 2048 Tamanho total da flash : 512 Mb A protecção contra escritura está desactivada. Está aberto o arquivo "C:\Documents and Settings\USER\Desktop\Download\SAMSUNG_GTS8500_Repair.mf"... Escritura da secção BOOT. Aguarde, por favor... Terminado Escritura da secção UPCH. Aguarde, por favor... Terminado IMEI corrigido... Terminado Desconectado.

Compartilhar este post


Link para o post
Compartilhar em outros sites

Medusa JTAG Firmware version 1.1.0. Medusa JTAG Hardware S64 revision C. Detected TAP ID: 203C00E1, IR Length = 4. Velocidade JTAG : Auto (RTCK) Nível de VREF : 2.58 V Tipo do núcleo : Qualcomm MSM7227 ID do núcleo: 203C00E1 Tipo da flash: ST Micro 512Mb ID da flash: 002055BC Tamanho da página: 2048 bytes Tamanho do bloco: 64 páginas (128 Kb) Quantidade dos blocos : 4096 Tamanho total da flash : 512 Mb A protecção contra escritura está desactivada. Conexão acertada Leitura da secção TA. Aguarde, por favor... Terminado TA section has been backed up to "C:\Arquivos de programas\GsmServer\Medusa\Firmware\Sony Ericsson U20a TA Backup 27-04-2012 16_09_02.mf". Borrando secção TA. Aguarde, por favor... Terminado Repairing. Please wait... Terminado post-132-139967773561_thumb.jpg

Compartilhar este post


Link para o post
Compartilhar em outros sites

LG E435f boot reparado com sucesso.



Log started at 20/09/2017 13:07:02 ...
Welcome to Medusa Box Software version 2.6.1.4
Connecting to server
Retrieving files list
Downloading file "C:\Program Files\GsmServer\Medusa\Firmware\LG_E435F_Repair.mf"...
Operating Mode: EasyRepair Mode
Selected device model: LG E435F USB
Connecting. Please wait...
MI: Loading Medusa Device Server V2.USB.
MI: Connecting to Device Server.
MI: Initializing.
MI: Flash ID = 0xE0900001.
Interface   : USB
CPU         : Qualcomm MSM7225
Storage Device: Hynix eMMC H4G1d
Device ID     : 00900001
 Block size   : 512 bytes
 Blocks       : 7569408
 Storage size : 3696 Mb
Opening "C:\Program Files\GsmServer\Medusa\Firmware\LG_E435F_Repair.mf" file...
Writing BOOT section. Please wait... Done
Disconnected

Compartilhar este post


Link para o post
Compartilhar em outros sites

SM-G532MT  J2 Primei  morto , apois   fazer flash  de 4 partes...

Levantando normalmente via  ytag.

Meritos: AlexC3 grande força em  jogar os arquivos...






Welcome to Medusa Pro Software version 1.4.5.
Started.
Reader #0: Alcor Micro USB Smart Card Reader 0
Reader #1: Alcor Micro USB Smart Card Reader 1

Please disconnect battery and USB cable.

Model Settings:
Interface : eMMC
Voltage   : 1.8V
Bus Mode  : 1 bit
Bus speed : Auto

Connecting...
Device       : Samsung eMMC Q316BB
Page size    : 512 B
Block size   : 512 B
Block count  : 30777344
Size         : 14.68 GB
---------------------------------------------------------------
CID Info

CID                   : 15010051333136424200E879F2D714ED
Manufacturer ID       : 0X15
Device/BGA            : BGA (Discrete embedded)
OEM/Application ID    : 0X00
Product name          : Q316BB
Product revision      : 0.0
Product serial number : (hex) E879F2D7
Manufacturing date    : 01/2017
---------------------------------------------------------------
CSD Info

CSD                   : D02701320F5903FFF6DBFFEF8E40400D
CSD structure         : CSD version No. 1.2
SPEC version          : 4.1, 4.2, 4.3, 4.4, 4.41, 4.5,
                        4.51, 5.0, 5.01, 5.1
Data read access time1: 15 ms
TRAN speed            : 26 MHz
READ block length     : 512 Bytes
WP group enable       : YES
PERM_WRITE_PROTECT    : NO
TMP_WRITE_PROTECT     : NO
---------------------------------------------------------------
EXTCSD Info

Revision 1.7 (for MMC v5.0, v5.01)
Erase block size      : 512 Kbytes
Boot1 size            : 4096 Kbytes
Boot2 size            : 4096 Kbytes
RPMB size             : 4096 Kbytes

Partition config      : 01001000
Boot partition enable : Boot partition 1 (Bus width = 1Bit)
Boot ACK              : Boot acknowledge sent during boot operation Bit

Boot bus conditions   : 00000000
Boot bus width        : x1 (sdr) or x4 (ddr) bus width in boot operation mode (default)
Reset boot bus conditions   : Reset bus width to x1, single data rate and backward compatible timings after boot operation (default)
Boot mode             : Use single data rate + backward compatible timings in boot operation (default)

Partitioning support  : Device supports partitioning features
Enhanced attribute    : Device can have enhanced technological features in partitions and user data area.
Max enhanced data size: 7692288 Kbytes
Partitions attribute  : 0x0
Part setting completed: 0x0
GP partition 1 size   : 0 b
GP partition 2 size   : 0 b
GP partition 3 size   : 0 b
GP partition 4 size   : 0 b
Enhanced area size    : (0x0) 0 b
Enhanced area start   : (0x0) 0 b

Backup EXT_CSD saved to file C:/Program Files/Medusa Pro Software/EXT_CSD Backups/Q316BB_09_10_2017_11_06_07.bin.
Connect successful.
---------------------------------------------------------------
SW: 1.4.5; FW: 1.22.
P00: GPT              (00000000, 00002000)
P01: BOTA0            (00002000, 00002000)
P02: nvram            (00004000, 00004000)
P03: lk               (00008000, 00001000)
P04: BOTA1            (00009000, 00001000)
P05: secro            (0000A000, 00003800)
P06: seccfg           (0000D800, 00000400)
P07: efuse            (0000DC00, 00000400)
P08: tee1             (0000E000, 00003000)
P09: BOTA2            (00011000, 00003000)
P10: EFS              (00014000, 00004000)
P11: nvdata           (00018000, 00010000)
P12: PARAM            (00028000, 00004000)
P13: recovery         (0002C000, 00008000)
P14: boot             (00034000, 00008000)
P15: md1img           (0003C000, 00010000)
P16: md1dsp           (0004C000, 00002000)
P17: keystore         (0004E000, 00004000)
P18: omekeystore      (00052000, 00001C00)
P19: proinfo          (00053C00, 00001400)
P20: para             (00055000, 00000400)
P21: PERSISTENT       (00055400, 00000400)
P22: STEADY           (00055800, 00000800)
P23: protect1         (00056000, 00004000)
P24: protect2         (0005A000, 00004000)
P25: RESERVE2         (0005E000, 00002000)
P26: system           (00060000, 00604000)
P27: cache            (00664000, 000C8000)
P28: hidden           (0072C000, 0001E000)
P29: userdata         (0074A000, 0160E000)

Disconnected.

Please disconnect battery and USB cable.

Model Settings:
Interface : eMMC
Voltage   : 1.8V
Bus Mode  : 1 bit
Bus speed : Auto

Connecting...
Device       : Samsung eMMC Q316BB
Page size    : 512 B
Block size   : 512 B
Block count  : 30777344
Size         : 14.68 GB
---------------------------------------------------------------
CID Info

CID                   : 15010051333136424200E879F2D714ED
Manufacturer ID       : 0X15
Device/BGA            : BGA (Discrete embedded)
OEM/Application ID    : 0X00
Product name          : Q316BB
Product revision      : 0.0
Product serial number : (hex) E879F2D7
Manufacturing date    : 01/2017
---------------------------------------------------------------
CSD Info

CSD                   : D02701320F5903FFF6DBFFEF8E40400D
CSD structure         : CSD version No. 1.2
SPEC version          : 4.1, 4.2, 4.3, 4.4, 4.41, 4.5,
                        4.51, 5.0, 5.01, 5.1
Data read access time1: 15 ms
TRAN speed            : 26 MHz
READ block length     : 512 Bytes
WP group enable       : YES
PERM_WRITE_PROTECT    : NO
TMP_WRITE_PROTECT     : NO
---------------------------------------------------------------
EXTCSD Info

Revision 1.7 (for MMC v5.0, v5.01)
Erase block size      : 512 Kbytes
Boot1 size            : 4096 Kbytes
Boot2 size            : 4096 Kbytes
RPMB size             : 4096 Kbytes

Partition config      : 01001000
Boot partition enable : Boot partition 1 (Bus width = 1Bit)
Boot ACK              : Boot acknowledge sent during boot operation Bit

Boot bus conditions   : 00000000
Boot bus width        : x1 (sdr) or x4 (ddr) bus width in boot operation mode (default)
Reset boot bus conditions   : Reset bus width to x1, single data rate and backward compatible timings after boot operation (default)
Boot mode             : Use single data rate + backward compatible timings in boot operation (default)

Partitioning support  : Device supports partitioning features
Enhanced attribute    : Device can have enhanced technological features in partitions and user data area.
Max enhanced data size: 7692288 Kbytes
Partitions attribute  : 0x0
Part setting completed: 0x0
GP partition 1 size   : 0 b
GP partition 2 size   : 0 b
GP partition 3 size   : 0 b
GP partition 4 size   : 0 b
Enhanced area size    : (0x0) 0 b
Enhanced area start   : (0x0) 0 b

---------------------------------------------------------------Searching Android build info...Ok

Disk/Image size       : ab400000 bytes
Device sector size    : 512 bytes
Partition offset      : 393216
Number of sectors     : 6307840
Device Manufacturer   : samsung
Device Platform       : mt6737t
Build ID              : MMB29T
Display Build ID      : MMB29T.G532MTVJU1APK2
Release ID            : 6.0.1
Device Model          : SM-G532MT
Device Name           : grandppltedtvvj
Architecture ABI      : armeabi-v7a
Architecture ABI2     : armeabi
Architecture ABI List : armeabi-v7a,armeabi
Build Description     : grandppltedtvvj-user 6.0.1 MMB29T G532MTVJU1APK2 release-keys

Backup EXT_CSD saved to file C:/Program Files/Medusa Pro Software/EXT_CSD Backups/Q316BB_09_10_2017_11_15_41.bin.
Connect successful.
---------------------------------------------------------------
SW: 1.4.5; FW: 1.22.
P00: GPT              (00000000, 00002000)
P01: BOTA0            (00002000, 00002000)
P02: nvram            (00004000, 00004000)
P03: lk               (00008000, 00001000)
P04: BOTA1            (00009000, 00001000)
P05: secro            (0000A000, 00003800)
P06: seccfg           (0000D800, 00000400)
P07: efuse            (0000DC00, 00000400)
P08: tee1             (0000E000, 00003000)
P09: BOTA2            (00011000, 00003000)
P10: EFS              (00014000, 00004000)
P11: nvdata           (00018000, 00010000)
P12: PARAM            (00028000, 00004000)
P13: recovery         (0002C000, 00008000)
P14: boot             (00034000, 00008000)
P15: md1img           (0003C000, 00010000)
P16: md1dsp           (0004C000, 00002000)
P17: keystore         (0004E000, 00004000)
P18: omekeystore      (00052000, 00001C00)
P19: proinfo          (00053C00, 00001400)
P20: para             (00055000, 00000400)
P21: PERSISTENT       (00055400, 00000400)
P22: STEADY           (00055800, 00000800)
P23: protect1         (00056000, 00004000)
P24: protect2         (0005A000, 00004000)
P25: RESERVE2         (0005E000, 00002000)
P26: system           (00060000, 00604000)
P27: cache            (00664000, 000C8000)
P28: hidden           (0072C000, 0001E000)
P29: userdata         (0074A000, 0160E000)
Disconnected.

Please disconnect battery and USB cable.

Model Settings:
Interface : eMMC
Brand     : Samsung
Model     : SM-G532F
SRF       : C:/Program Files/Medusa Pro Software/firmwareFolder/SAMSUNG_SM-G532F_EMMC_QN16BB.srf
Voltage   : 1.8V
Bus Mode  : 1 bit
Bus speed : Auto

Connecting...
Device       : Samsung eMMC Q316BB
Page size    : 512 B
Block size   : 512 B
Block count  : 30777344
Size         : 14.68 GB
---------------------------------------------------------------
CID Info

CID                   : 15010051333136424200E879F2D714ED
Manufacturer ID       : 0X15
Device/BGA            : BGA (Discrete embedded)
OEM/Application ID    : 0X00
Product name          : Q316BB
Product revision      : 0.0
Product serial number : (hex) E879F2D7
Manufacturing date    : 01/2017
---------------------------------------------------------------
CSD Info

CSD                   : D02701320F5903FFF6DBFFEF8E40400D
CSD structure         : CSD version No. 1.2
SPEC version          : 4.1, 4.2, 4.3, 4.4, 4.41, 4.5,
                        4.51, 5.0, 5.01, 5.1
Data read access time1: 15 ms
TRAN speed            : 26 MHz
READ block length     : 512 Bytes
WP group enable       : YES
PERM_WRITE_PROTECT    : NO
TMP_WRITE_PROTECT     : NO
---------------------------------------------------------------
EXTCSD Info

Revision 1.7 (for MMC v5.0, v5.01)
Erase block size      : 512 Kbytes
Boot1 size            : 4096 Kbytes
Boot2 size            : 4096 Kbytes
RPMB size             : 4096 Kbytes

Partition config      : 01001000
Boot partition enable : Boot partition 1 (Bus width = 1Bit)
Boot ACK              : Boot acknowledge sent during boot operation Bit

Boot bus conditions   : 00000000
Boot bus width        : x1 (sdr) or x4 (ddr) bus width in boot operation mode (default)
Reset boot bus conditions   : Reset bus width to x1, single data rate and backward compatible timings after boot operation (default)
Boot mode             : Use single data rate + backward compatible timings in boot operation (default)

Partitioning support  : Device supports partitioning features
Enhanced attribute    : Device can have enhanced technological features in partitions and user data area.
Max enhanced data size: 7692288 Kbytes
Partitions attribute  : 0x0
Part setting completed: 0x0
GP partition 1 size   : 0 b
GP partition 2 size   : 0 b
GP partition 3 size   : 0 b
GP partition 4 size   : 0 b
Enhanced area size    : (0x0) 0 b
Enhanced area start   : (0x0) 0 b

Backup EXT_CSD saved to file C:/Program Files/Medusa Pro Software/EXT_CSD Backups/Q316BB_09_10_2017_11_16_10.bin.
Connect successful.
---------------------------------------------------------------
SW: 1.4.5; FW: 1.22.
P00: GPT              (00000000, 00002000)
P01: BOTA0            (00002000, 00002000)
P02: nvram            (00004000, 00004000)
P03: lk               (00008000, 00001000)
P04: BOTA1            (00009000, 00001000)
P05: secro            (0000A000, 00003800)
P06: seccfg           (0000D800, 00000400)
P07: efuse            (0000DC00, 00000400)
P08: tee1             (0000E000, 00003000)
P09: BOTA2            (00011000, 00003000)
P10: EFS              (00014000, 00004000)
P11: nvdata           (00018000, 00010000)
P12: PARAM            (00028000, 00004000)
P13: recovery         (0002C000, 00008000)
P14: boot             (00034000, 00008000)
P15: md1img           (0003C000, 00010000)
P16: md1dsp           (0004C000, 00002000)
P17: keystore         (0004E000, 00004000)
P18: omekeystore      (00052000, 00001C00)
P19: proinfo          (00053C00, 00001400)
P20: para             (00055000, 00000400)
P21: PERSISTENT       (00055400, 00000400)
P22: STEADY           (00055800, 00000800)
P23: protect1         (00056000, 00004000)
P24: protect2         (0005A000, 00004000)
P25: RESERVE2         (0005E000, 00002000)
P26: system           (00060000, 00604000)
P27: cache            (00664000, 000C8000)
P28: hidden           (0072C000, 0001E000)
P29: userdata         (0074A000, 0160E000)
Repairing from file "C:/Program Files/Medusa Pro Software/firmwareFolder/SAMSUNG_SM-G532F_EMMC_QN16BB.srf".
Write data verification is enabled.

Switched to boot area partition 1.
Writing BOOT1 partition...    Done.

Switched to user area.
Writing GPT partition...    Done.
Writing BOTA0 partition...    Done.
Writing lk partition...    Done.
Writing BOTA1 partition...    Done.
Writing secro partition...    Done.
Writing seccfg partition...    Done.
Writing efuse partition...    Done.
Writing tee1 partition...    Done.
Writing BOTA2 partition...    Done.
Writing EFS partition...    Done.
Writing PARAM partition...    Done.
Writing recovery partition...    Done.
Writing boot partition...    Done.
Writing md1img partition...    Done.
Writing md1dsp partition...    Done.
Writing keystore partition...    Done.
Writing omekeystore partition...    Done.
Writing proinfo partition...    Done.
Writing para partition...    Done.
Writing PERSISTENT partition...    Done.
Writing STEADY partition...    Done.

Smart Repair is successfully complete.
SW: 1.4.5; FW: 1.22.
Disconnected.

Please disconnect battery and USB cable.

Model Settings:
Interface : eMMC
Brand     : Samsung
Model     : SM-G532F
SRF       : C:/Program Files/Medusa Pro Software/firmwareFolder/SAMSUNG_SM-G532F_EMMC_QN16BB.srf
Voltage   : 1.8V
Bus Mode  : 1 bit
Bus speed : Auto

Connecting...
Device       : Samsung eMMC Q316BB
Page size    : 512 B
Block size   : 512 B
Block count  : 30777344
Size         : 14.68 GB
---------------------------------------------------------------
CID Info

CID                   : 15010051333136424200E879F2D714ED
Manufacturer ID       : 0X15
Device/BGA            : BGA (Discrete embedded)
OEM/Application ID    : 0X00
Product name          : Q316BB
Product revision      : 0.0
Product serial number : (hex) E879F2D7
Manufacturing date    : 01/2017
---------------------------------------------------------------
CSD Info

CSD                   : D02701320F5903FFF6DBFFEF8E40400D
CSD structure         : CSD version No. 1.2
SPEC version          : 4.1, 4.2, 4.3, 4.4, 4.41, 4.5,
                        4.51, 5.0, 5.01, 5.1
Data read access time1: 15 ms
TRAN speed            : 26 MHz
READ block length     : 512 Bytes
WP group enable       : YES
PERM_WRITE_PROTECT    : NO
TMP_WRITE_PROTECT     : NO
---------------------------------------------------------------
EXTCSD Info

Revision 1.7 (for MMC v5.0, v5.01)
Erase block size      : 512 Kbytes
Boot1 size            : 4096 Kbytes
Boot2 size            : 4096 Kbytes
RPMB size             : 4096 Kbytes

Partition config      : 01001000
Boot partition enable : Boot partition 1 (Bus width = 1Bit)
Boot ACK              : Boot acknowledge sent during boot operation Bit

Boot bus conditions   : 00000000
Boot bus width        : x1 (sdr) or x4 (ddr) bus width in boot operation mode (default)
Reset boot bus conditions   : Reset bus width to x1, single data rate and backward compatible timings after boot operation (default)
Boot mode             : Use single data rate + backward compatible timings in boot operation (default)

Partitioning support  : Device supports partitioning features
Enhanced attribute    : Device can have enhanced technological features in partitions and user data area.
Max enhanced data size: 7692288 Kbytes
Partitions attribute  : 0x0
Part setting completed: 0x0
GP partition 1 size   : 0 b
GP partition 2 size   : 0 b
GP partition 3 size   : 0 b
GP partition 4 size   : 0 b
Enhanced area size    : (0x0) 0 b
Enhanced area start   : (0x0) 0 b

---------------------------------------------------------------Searching Android build info...Ok

Disk/Image size       : ab400000 bytes
Device sector size    : 512 bytes
Partition offset      : 393216
Number of sectors     : 6307840
Device Manufacturer   : samsung
Device Platform       : mt6737t
Build ID              : MMB29T
Display Build ID      : MMB29T.G532MTVJU1APK2
Release ID            : 6.0.1
Device Model          : SM-G532MT
Device Name           : grandppltedtvvj
Architecture ABI      : armeabi-v7a
Architecture ABI2     : armeabi
Architecture ABI List : armeabi-v7a,armeabi
Build Description     : grandppltedtvvj-user 6.0.1 MMB29T G532MTVJU1APK2 release-keys

Backup EXT_CSD saved to file C:/Program Files/Medusa Pro Software/EXT_CSD Backups/Q316BB_09_10_2017_11_17_28.bin.
Connect successful.
---------------------------------------------------------------
SW: 1.4.5; FW: 1.22.
P00: GPT              (00000000, 00002000)
P01: BOTA0            (00002000, 00002000)
P02: nvram            (00004000, 00004000)
P03: lk               (00008000, 00001000)
P04: BOTA1            (00009000, 00001000)
P05: secro            (0000A000, 00003800)
P06: seccfg           (0000D800, 00000400)
P07: efuse            (0000DC00, 00000400)
P08: tee1             (0000E000, 00003000)
P09: BOTA2            (00011000, 00003000)
P10: EFS              (00014000, 00004000)
P11: nvdata           (00018000, 00010000)
P12: PARAM            (00028000, 00004000)
P13: recovery         (0002C000, 00008000)
P14: boot             (00034000, 00008000)
P15: md1img           (0003C000, 00010000)
P16: md1dsp           (0004C000, 00002000)
P17: keystore         (0004E000, 00004000)
P18: omekeystore      (00052000, 00001C00)
P19: proinfo          (00053C00, 00001400)
P20: para             (00055000, 00000400)
P21: PERSISTENT       (00055400, 00000400)
P22: STEADY           (00055800, 00000800)
P23: protect1         (00056000, 00004000)
P24: protect2         (0005A000, 00004000)
P25: RESERVE2         (0005E000, 00002000)
P26: system           (00060000, 00604000)
P27: cache            (00664000, 000C8000)
P28: hidden           (0072C000, 0001E000)
P29: userdata         (0074A000, 00744000)
Canceling process...
Disconnected.

Please disconnect battery and USB cable.

Model Settings:
Interface : eMMC
Brand     : Samsung
Model     : SM-G532F
SRF       : C:/Program Files/Medusa Pro Software/firmwareFolder/SAMSUNG_SM-G532F_EMMC_QN16BB.srf
Voltage   : 1.8V
Bus Mode  : 1 bit
Bus speed : Auto

Connecting...
Device       : Samsung eMMC Q316BB
Page size    : 512 B
Block size   : 512 B
Block count  : 30777344
Size         : 14.68 GB
---------------------------------------------------------------
CID Info

CID                   : 15010051333136424200E879F2D714ED
Manufacturer ID       : 0X15
Device/BGA            : BGA (Discrete embedded)
OEM/Application ID    : 0X00
Product name          : Q316BB
Product revision      : 0.0
Product serial number : (hex) E879F2D7
Manufacturing date    : 01/2017
---------------------------------------------------------------
CSD Info

CSD                   : D02701320F5903FFF6DBFFEF8E40400D
CSD structure         : CSD version No. 1.2
SPEC version          : 4.1, 4.2, 4.3, 4.4, 4.41, 4.5,
                        4.51, 5.0, 5.01, 5.1
Data read access time1: 15 ms
TRAN speed            : 26 MHz
READ block length     : 512 Bytes
WP group enable       : YES
PERM_WRITE_PROTECT    : NO
TMP_WRITE_PROTECT     : NO
---------------------------------------------------------------
EXTCSD Info

Revision 1.7 (for MMC v5.0, v5.01)
Erase block size      : 512 Kbytes
Boot1 size            : 4096 Kbytes
Boot2 size            : 4096 Kbytes
RPMB size             : 4096 Kbytes

Partition config      : 01001000
Boot partition enable : Boot partition 1 (Bus width = 1Bit)
Boot ACK              : Boot acknowledge sent during boot operation Bit

Boot bus conditions   : 00000000
Boot bus width        : x1 (sdr) or x4 (ddr) bus width in boot operation mode (default)
Reset boot bus conditions   : Reset bus width to x1, single data rate and backward compatible timings after boot operation (default)
Boot mode             : Use single data rate + backward compatible timings in boot operation (default)

Partitioning support  : Device supports partitioning features
Enhanced attribute    : Device can have enhanced technological features in partitions and user data area.
Max enhanced data size: 7692288 Kbytes
Partitions attribute  : 0x0
Part setting completed: 0x0
GP partition 1 size   : 0 b
GP partition 2 size   : 0 b
GP partition 3 size   : 0 b
GP partition 4 size   : 0 b
Enhanced area size    : (0x0) 0 b
Enhanced area start   : (0x0) 0 b

Backup EXT_CSD saved to file C:/Program Files/Medusa Pro Software/EXT_CSD Backups/Q316BB_09_10_2017_11_18_50.bin.
Connect successful.
---------------------------------------------------------------
SW: 1.4.5; FW: 1.22.
P00: GPT              (00000000, 00002000)
P01: BOTA0            (00002000, 00002000)
P02: nvram            (00004000, 00004000)
P03: lk               (00008000, 00001000)
P04: BOTA1            (00009000, 00001000)
P05: secro            (0000A000, 00003800)
P06: seccfg           (0000D800, 00000400)
P07: efuse            (0000DC00, 00000400)
P08: tee1             (0000E000, 00003000)
P09: BOTA2            (00011000, 00003000)
P10: EFS              (00014000, 00004000)
P11: nvdata           (00018000, 00010000)
P12: PARAM            (00028000, 00004000)
P13: recovery         (0002C000, 00008000)
P14: boot             (00034000, 00008000)
P15: md1img           (0003C000, 00010000)
P16: md1dsp           (0004C000, 00002000)
P17: keystore         (0004E000, 00004000)
P18: omekeystore      (00052000, 00001C00)
P19: proinfo          (00053C00, 00001400)
P20: para             (00055000, 00000400)
P21: PERSISTENT       (00055400, 00000400)
P22: STEADY           (00055800, 00000800)
P23: protect1         (00056000, 00004000)
P24: protect2         (0005A000, 00004000)
P25: RESERVE2         (0005E000, 00002000)
P26: system           (00060000, 00604000)
P27: cache            (00664000, 000C8000)
P28: hidden           (0072C000, 0001E000)
P29: userdata         (0074A000, 00744000)

Selected pit file: C:/Users/LOJA-EDCELL/Desktop/Galaxy_J2_PrimeTV_SM-G532MT_601_G532MTVJU1AQA2/GRANDPPLTE_CIS_SER.pit

Open file "C:/Users/LOJA-EDCELL/Desktop/Galaxy_J2_PrimeTV_SM-G532MT_601_G532MTVJU1AQA2/CSC_ZTO_G532MTZTO1AQA2_CL10457923_QB12322631_REV00_user_low_ship_MULTI_CERT.tar.md5".


Open file "C:/Users/LOJA-EDCELL/Desktop/Galaxy_J2_PrimeTV_SM-G532MT_601_G532MTVJU1AQA2/CP_G532MTVJU1AQA2_CL10457923_QB12322631_REV00_user_low_ship_MULTI_CERT.tar.md5".


Open file "C:/Users/LOJA-EDCELL/Desktop/Galaxy_J2_PrimeTV_SM-G532MT_601_G532MTVJU1AQA2/BL_G532MTVJU1AQA2_CL10457923_QB12322631_REV00_user_low_ship_MULTI_CERT.tar.md5".


Open file "C:/Users/LOJA-EDCELL/Desktop/Galaxy_J2_PrimeTV_SM-G532MT_601_G532MTVJU1AQA2/AP_G532MTVJU1AQA2_CL10457923_QB12322631_REV00_user_low_ship_MULTI_CERT.tar.md5".


Writing MBR...Done.
Writing primary GPT...Done.
Writing secondary GPT...Done.
Writing PIT
Write data verification is enabled.
Writing. Please wait...

Switched to boot area partition 1.
Writing partition BOOTLOADER...    Done.

Switched to user area.
Writing partition lk...    Done.
Writing partition secro...    Done.
Writing partition efuse...    Done.
Writing partition tee1...    Done.
Writing partition PARAM...    Done.
Writing partition recovery...    Done.
Writing partition boot...    Done.
Writing partition md1img...    Done.
Writing partition md1dsp...    Done.
Writing partition system...    Done.
Writing partition cache...    Done.
Writing partition hidden...    Done.
Writing partition userdata...    Done.
Writing is finished.
SW: 1.4.5; FW: 1.22.




BOOT  sm-g532mt.JPG

imei   1 jackson.jpg

imagem  2 jackson.jpg

Compartilhar este post


Link para o post
Compartilhar em outros sites

Crie uma conta ou entre para comentar

Você precisar ser um membro para fazer um comentário

Criar uma conta

Crie uma nova conta em nossa comunidade. É fácil!

Crie uma nova conta

Entrar

Já tem uma conta? Faça o login.

Entrar Agora

×
